FB30MDIY Solid Mahogany Body Electric Guitar DIY Kit,Tuner,3 picks, No-Soldering, H-H

This upgraded electric guitar DIY kit includes everything you need for building your own custom Electric Guitar. You will need only some basic tools and finishing supplies.

All challenging wood cutting and shaping is already done professionally, as well as fret levelling and dressing. No soldering design that makes your creation smoothly.

Click to Download

→ DIY Assembly Guide

→ Electronics Overview

→ Electronics Diagram

*Please Note, Instructions and Diagrams show a different guitar body shape but are still relevant for this DIY Kit. The wiring, parts and functionality are 100% identical between kits.

Specifications

Model                  FB30MDIY

Body                    Solid Mahogany w/white pickguard

Neck                    Mahogany, Bolt-on, Thin-C Profile

Neck radius                   15"

Fingerboard         Rosewood w/Dot inlays and side markers

Bridge                  Chrome Tune-O-Matic w/Loc-Tone stop tail

Frets                     22

Nut width             42mm (1.65")

Scale Length        628mm (24.72")

Body Depth         1.49" (38mm) / 1.69" (43mm, raised middle section)

Pickups                2 mini Humbuckers, chrome covered

Controls               Controls 2 Volume, 2 Tone, 3-way selector, silver-black Top Hat knobs

Truss Rod             2-way adjustable

Connections          All wiring has no-solder Plug-n-Play connectors, Completely no soldering needed.

Included               Truss rod key, 1/4" lead, String set, and 3 Picks
